Selected designs of sailing vessels and yachts:

Alexander von Humboldt II

	Main Particulars Type: Sail Training Bark Length o.a.: 65,00m Breadth: 10,00m Draught: 4,50m Status: Design and engineering Year: 2011	Further Information Project data General arrangement Interior plan
	Design Description Sail training vessel for world-wide service, as sucessor of the well kown 'Alexander von Humboldt'.

Schooner Avontuur

	Main Particulars Type: Cargo Sailing Schooner Length o.a.: 43,50m Breadth: 5,88m Draught: 2,28m Status: Design and engineering Year: 2016	Further Information Project data General arrangement Interior plan
	Design Description AVONTUUR is a 2-masted gaff schooner built in 1920. In 2014-2016 she was refitted to serve as sailing cargo ship and offer substainable transport.

Gabriella

	Main Particulars Type: 2-Masted Schooner Yacht Length o.a.: 30,50m Breadth: 6,00m Draught: 2,50m Status: Preliminary design Year: 1999	Further Information General arrangement Interior plan
	Design Description Traditional gaff schooner to use as private cruising yacht or exclusive charter vessel.

Calliope

	Main Particulars Type: Sail Training Barquentine Length o.a.: 56,00m Breadth: 9,50m Draught: 4,00m Status: Preliminary design Year: 2002	Further Information Project data General arrangement Interior plan Visualization
	Design Description The Calliope was especially designed to serve as floating classroom on world-wide long-time voyages with students of all grades, combining sailing experience with lessons and research on board.

Glamare 333

	Main Particulars Type: 4-Masted Schooner Yacht Length o.a.: 101,50m Breadth: 14,00m Draught: 5,50m Status: Preliminary design Year: 2004	Further Information Project data General arrangement Interior plan Visualization
	Design Description The bigger sister of the Glamare 300, incorporating a internal helicopter hangar. Design also attained a New Design Concept Award by the Boat International Magazine in 2004.

Glamare 300

	Main Particulars Type: 3-Masted Schooner Yacht Length o.a.: 93,80m Breadth: 14,00m Draught: 5,50m Status: Preliminary design Year: 2003	Further Information Project data General arrangement
	Design Description The preliminary design for this 300' schooner yacht is seeking for a symbiosis between the beauty of a classic yacht and state of the art technology.

Glamare 180

	Main Particulars Type: 2-Masted Schooner Yacht Length o.a.: 55,50m Breadth: 10,20m Draught: 3,85m Status: Preliminary design Year: 2004	Further Information Project data General arrangement Interior plan
	Design Description Charter yacht for worldwide expedition cruises with 16 guests. Design attained a New Design Concept Award by the Boat International Magazine in 2004.

Glamare 111 Classic

	Main Particulars Type: 2-Masted Schooner Yacht Length o.a.: 34,00m Breadth: 7,00m Draught: 5,20m Status: Preliminary design Year: 2004	Further Information Project data General arrangement Interior plan
	Design Description Exclusive schooner yacht with classic lines and wishbone rig.

Sail Training Barque 71m

	Main Particulars Type: Sail Training Barque Length o.a.: 71,00m Breadth: 10,00m Draught: 5,00m Status: Concept design proposal Year: 2015	Further Information Project data General arrangement Interior plan
	Design Description Concept design of a sail training vessel for 90 trainees plus permanent crew of 30.

STV101

	Main Particulars Type: Sail Training Ship Length o.a.: 101,50m Breadth: 12,60m Draught: 6,00m Status: Preliminary design Year: 2003	Further Information Project data General arrangement Interior plan
	Design Description Design of a civil sail training vessel for 100 trainees plus permanent crew of 40.

Passatwind

	Main Particulars Type: Sail Training Bark Length o.a.: 62,80m Breadth: 9,50m Draught: 4,00m Status: Preliminary design Year: 2002	Further Information Project data General arrangement Interior plan
	Design Description Sail training vessel for world-wide service. Lines plan in dependence on the Indonesian sail training ship Dewarutji, built 1953 in Hamburg.
